Siemens SCALANCE X308-2 Compact Operating Instructions

7.2 Connectors and electrical data
Table 7-4 Connection for end devices or network components
Device variant Electrical
over twisted pair
Optical
over fiber-optic cable
X304-2FE 4 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
2 x SC duplex socket (MM)
(100 Mbps, full duplex to
100BaseFX)
X306-1LD FE 6 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
1 x SC duplex socket (SM)
(100 Mbps, full duplex to
100BaseFX)
X307-3 7 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
3 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseSX)
X307-3LD 7 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
3 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseLX)
X308-2 7 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
1 x RJ-45 socket with MDI-X pinning
10/100/1000 Mbps (half/ full duplex)
2 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseSX)
X308-2LD 7 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
1 x RJ‑45 jacks with MDI‑X assignment
10/100/1000 Mbps (half / full duplex)
2 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseLX)
X308-2LH 7 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
1 x RJ-45 socket with MDI-X pinning
10/100/1000 Mbps (half/ full duplex)
2 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseLX)
X308-2LH+ 7 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
1 x RJ‑45 jacks with MDI‑X assignment
10/100/1000 Mbps (half / full duplex)
2 x SC duplex sockets
(1000 Mbps, full duplex to
1000BaseLX)
X310 7 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
3 x RJ‑45 jacks with MDI‑X assignment
10/100/1000 Mbps (half / full duplex)
-
X310FE 10 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
-
X320-1 FE 20 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
1 x SC duplex socket (MM)
(100 Mbps, full duplex to
100BaseFX)
X320-3LD FE 20 x RJ‑45 jacks with MDI‑X assignment
10/100 Mbps (half / full duplex)
1 x SC duplex socket (MM)
2 x SC duplex sockets (SM)
(100 Mbps, full duplex to
100BaseFX)
Technical data
7.2 Connectors and electrical data
SCALANCE X-300
62 Compact Operating Instructions, 11/2019, A5E00982643-18
