Documentation on configuration
You will find detailed information on configuring the devices in the configuration manual:
● SIMATIC NET: Industrial Ethernet switches SCALANCE X-300 / X-400 Configuration
Manual
You will find the Configuration Manual here:
● On the data medium that ships with some products:
– Product CD / product DVD
– SIMATIC NET Manual Collection
● On the Internet pages of Siemens Industry Online Support (
https://
support.industry.siemens.com/cs/ww/en/ps/15297/man).
Additional documentation
The manual
● "SIMATIC NET Industrial Ethernet Twisted Pair and Fiber Optic Networks (https://
support.industry.siemens.com/cs/ww/en/view/1172207)"
contains additional information on other SIMATIC NET products that you can operate along
with the devices of the SCALANCE X‑300 product line in an Industrial Ethernet network.
Integration in STEP 7 projects
The current GSDML file must be used for integration in STEP 7 V5.4 SP5 projects. This applies
to all products covered by these operating instructions.
You can obtain the relevant GSD file from the Internet under the following entry ID:
46183514 (https://support.industry.siemens.com/cs/ww/en/view/46183514)
You will find the file for the firmware update V3.3.1 for X-300 under entry ID "46183538".
Further documentation
In the system manuals "Industrial Ethernet / PROFINET Industrial Ethernet" and "Industrial
Ethernet / PROFINET passive network components", you will find information on other
SIMATIC NET products that you can operate along with the devices of this product line in an
Industrial Ethernet network.
There, you will find among other things optical performance data of the communications partner
that you require for the installation.
Introduction
SCALANCE X-300
Compact Operating Instructions, 11/2019, A5E00982643-18 7
