Table A-42 Bits "D-OUT"
Group Bit Meaning Comment
D-OUT 0 Output 1 Digital output "close"
1 Output 2 Not available
2 Output 3 Digital output "open"
3 -
15
Reserved
Table A-43 TZW data structure for value "Button"
TZW3, TZW4, TZW5
15 - 3 2 1 0
Reserved Button
Table A-44 Bits "Button"
Group Bit Meaning Comment
Button 0 Service button S401, Service button learn run
1 Close button S403, Service button close
2 Button Open S402, Service button OPEN
3 - 15 Reserved
A.2 Pro󹪝les and adjustment ranges
A.2.1 Pro󹪝le name
SIDOOR …
Pro󹪝le M3 R / L M4 R / L M5 R / L
MDG3 R / L MDG4 R / L MDG5 R / L
1 M3/MDG3 default prof. M4/MDG4 default prof. M5/MDG5 default prof.
Appendices
A.2 Pro󹪝les and adjustment ranges
ATD4xxW for industrial applications
System Manual, 06/2022, A5E51901827B AA 329
