Siemens simatic c7-621 Hardware Installation Guide

2-4
C7-621 / C7-621 AS-i Control Systems
C79000-G7076-C621-01
120
16868
159+0,5
110
+0,5
Cutout in front panel
Figure 2-2 Dimension Drawings for the C7
Figure 2-3 Securing Post Before Engaging
➀
Figure 2-4 Securing Post Engaged, with Screw
Securing Post
Before Engaging
Securing Post
Engaged
Installing and Preparing the C7
