2-5
C7-621 / C7-621 AS-i Control Systems
C79000-G7076-C621-01
To release a securing post, follow the steps outlined below:
Step Action
1. Loosen the screw.
2. Lever the securing post upwards (➀ in Figure 2-5).
3. Lever the securing post out of the guide (➁ in Figure 2-5).
➁
➀
Figure 2-5 Removing the Securing Post
Releasing the
Securing Post
Installing and Preparing the C7
