Description
The I/O module consists of the following components:
2
1
3
5
4
6
9
8
7
10
DI
DIAG
MT
.0
.2
.4
.6
.0
X
3
2
4
.2
.4
.6
PWR
.1
.3
.5
.7
.1
.3
.5
.7
L+ 24VDC M
MAX. 10 A
6DL1161-6BH00-0PH1
DI a
DI b
16x24VDC
PA SMART+
① Output disable switch ⑧ LED for maintenance
② Function status and rmware ver‐
sion
⑨ LED for diagnostics
③ Serial number ⑩ Module type and designation
④ Article number
⑤ LED for supply voltage
⑥ LEDs for channel status
⑦ 2D matrix code
4.2 Accessories [ID:151040216459]
Denition
Accessories for the I/O module must be ordered separately.
Product overview
4.2Accessories
DI 16x24VDC PA
12 Equipment Manual, 06/2023, A5E51654101-AA
