Error_
Code_
1
Error_
Code_
2
Cause Remedy
0xE1 0x01 Reserved bit set Check and correct the parameters
0xE1 0x02 Invalid diagnostics enable bit set for operating mode
0xE1 0x03 Invalid hardware interrupt enable bit set for operating
mode
0xE1 0x07 Invalid coding for input delay
0xE1 0x0B Invalid coding for pulse stretching
0xE1 0x0E Invalid redundancy parameter assignment
A.2 Parameter assignment and structure of the module/channel
parameters [ID:151040913547]
Structure of data record 128
Data record 128 has a length of 76 bytes.
It contains module parameters as well as channel or technology parameters of the 16
channels; 4 bytes each.
Channel 0
Byte 12
Channel 1
Byte 16
Digital input
Digital input
Digital input
Digital input
Digital input
Channel 2
Channel 3
Channel 15
Byte 20
Byte 24
Byte 72
Header information (module)
Module parameters
Header information (channel)
Byte 0
Byte 4
Byte 10
FigureA-1 Structure of data record 128
Drivers, parameters, diagnostics messages and address space
A.2Parameter assignment and structure of the module/channel parameters
DI 16x24VDC PA
38 Equipment Manual, 06/2023, A5E51654101-AA
