Displays and interrupts
7
7.1 Status and error displays [ID:151040603019]
De󹪝nition
The LED displays are status and error indicators.
Diagnostics messages and maintenance events, as well as their possible causes or solutions,
are described in the diagnostics messages and maintenance events.
Diagnostics messages (Page41)
Description
The following 󹪝gure explains the LED displays of the I/O module.
2
1
4
3
DI
DIAG MT
.0
.2
.4
.6
.0
X
3
2
4
.2
PWR
.1
.3
.5
.7
.1
L+ 24VDC M
MAX. 10 A
6DL1161-6BH00-0PH1
16x24VDC
PA SMART+
.3
.4
.5
.6
.7
DI aDI b
① DIAG LED (Page28) (green/red)
② MT LED (Page28) (yellow)
③ PWR LED (Page29) (green)
④ Channel status LEDs (Page29) (green)
DI 16x24VDC PA
Equipment Manual, 06/2023, A5E51654101-AA 27
