A.3 Diagnostics messages [ID:151040988811]
Diagnostics alarms
A diagnostics message is generated for each diagnostics event and the DIAG LED on the
DI16×24VDC PA 󹪞ashes red or the MT LED lights up yellow.
The diagnostics messages can be read in the diagnostics bu󹪜er of the CPU, for example.
Diagnostic messages are assigned either channel-speci󹪝c to an input or assigned as module
messages to all inputs. All channels are switched o󹪜 for diagnostics messages that a󹪜ect
the entire module. Only the corresponding digital input is a󹪜ected by diagnostics messages,
which refer to individual channels.
Table A-1 Diagnostic messages, their meanings and remedy options
Diagnostics mes‐
sage
Error
code
Assignment Meaning Remedy
Wire break 6
H
Channel Impedance of encoder circuitry is too high Use another type of encoder or
wiring, for example, use con‐
ductors with a larger cross-sec‐
tion
Wire break between the module and sensor Connect the cable
Channel not connected (open)
• Disable diagnostics
• Connect encoder contacts
with a 15kΩ to 18kΩ re‐
sistor
1)
• Switch o󹪜 wire break check
Parameter assign‐
ment error
10
H
Module
• Parameter assignment does not match
the terminal block used
• Incorrect parameter assignment
• Correct the parameter as‐
signment
• Check terminal block
2)
Supply voltage
missing
11
H
Module Missing or insu󹪟cient supply voltageL+
• Check the supply voltage
L+ on the terminal block
• Check terminal block
Hardware interrupt
lost
16
H
Module Error is reported because the events occur
faster than they can be processed in the
system.

Channel/compo‐
nent temporarily
unavailable
1F
H
Module Firmware update is in progress or has been
canceled during the update.
The module does not read any process val‐
ues in this state.
• Restart the 󹪝rmware up‐
date
• Wait for 󹪝rmware update
Short-circuit/over‐
load at external en‐
coder supply
10E
H
Channel Short-circuit of the encoder supply to
ground
Correction of the process wir‐
ing
Shutdown on but‐
ton activation
122
H
Module The output disable switch was activated. Pull module
Inconsistent param‐
eter assignment
123
H
Module Errors in the redundancy parameters sent
to the module
Check the parameter assign‐
ment
Drivers, parameters, diagnostics messages and address space
A.3Diagnostics messages
DI 16x24VDC PA
Equipment Manual, 06/2023, A5E51654101-AA 41
