5.1 Pin assignment [ID:151040259851]
De󹪝nition
The terminal assignment provides information about the arrangement and marking of the
terminals when wiring a connector.
Description
The general pin assignment is structured as follows:
Terminal Assignment Terminal Assignment Explanations
1 DI a /DI.0+ 2 DI a /DI.1+ DI a /DI.n+: Input signal, channeln (0…7)
DI b /DI.n+: Input signal, channeln+8 (8…15)
UV a /UV.n: Sensor supply, channeln (0...7)
UV b /UV.n: Sensor supply, channel n+8 (8…15)
1P1: Supply voltage L+ of the voltage bus 1P
2P1: Supply voltage L+ of the voltage bus 2P
1P2: Ground reference of the voltage bus 1P
2P2: Ground reference of the voltage bus 2P
1P1 L+ 24VDC M 1P2
2P1 L+ 24VDC M 2P2
MAX. 10 A
UV6
UV0
UV2
UV4
UV7
UV1
UV3
UV5
UV a DI a
32
UV b DI b
7
1
3
5
DI.6+
DI.0+
DI.2+
DI.4+
DI.7+
DI.1+
DI.3+
DI.5+
UV6
UV0
UV2
UV4
UV7
UV1
UV3
UV5
DI.6+
DI.0+
DI.2+
DI.4+
DI.7+
DI.1+
DI.3+
DI.5+
8
2
4
6
15
9
11
13
16
10
12
14
23
17
19
21
31
25
27
29
24
18
20
22
26
28
30
3 DI a /DI.2+ 4 DI a /DI.3+
5 DI a /DI.4+ 6 DI a /DI.5+
7 DI a /DI.6+ 8 DI a /DI.7+
9 DI b /DI.0+ 10 DI b /DI.1+
11 DI b /DI.2+ 12 DI b /DI.3+
13 DI b /DI.4+ 14 DI b /DI.5+
15 DI b /DI.6+ 16 DI b /DI.7+
17 UV a/UV0 18 UV a/UV1
19 UV a/UV2 20 UV a/UV3
21 UV a/UV4 22 UV a/UV5
23 UV a/UV6 24 UV a/UV7
25 UV b/UV0 26 UV b/UV1
27 UV b/UV2 28 UV b/UV3
29 UV b/UV4 30 UV b/UV5
31 UV b/UV6 32 UV b/UV7
1P1 L+ 1P2 M
2P1
1
L+ 2P2 M
1
If the module is plugged into a TB45R-P32 terminal block suitable for IO redundancy, the potential at this terminal is 1P3.
DI 16x24VDC PA
Equipment Manual, 06/2023, A5E51654101-AA 15
