Configuring the SIMATIC Field PG
5-9
SIMATIC Field PG Manual
A5E00075760-04
Option “Boot Options”
The following submenu appears when you select the option “Boot Options” in the
main menu:
PhoenixBIOS Setup Utility
Item Specific Help
QuickBoot Mode:
ESC Exit
Select Item
Select Menu
+ / –
Select
Change Values
Sub-Menu
F9
F10
Setup Defaults
Save and Exit
SETUP prompt: [Enabled]
POST Errors: [Enabled]
Floppy check:
Allows the system to
skip certain tests
while booting. This
will decrease the
time needed to boot
the system.
Enter
Help
F1
Main
Boot Options
[Enabled]
Summary screen:
[Disabled]
[Disabled]
Fig. 5-5 ”Boot Options” Submenu
Quick Boot
Mode
Some hardware tests are skipped to speed up the boot procedure.
SETUP prompt The message PRESS <F2> to enter Setup appears at the bottom of the
screen during the system run-up phase.
POST Errors The boot process is stopped if an error is detected; you must press F1 to
confirm. Enter “Disabled”to avoid the necessity of acknowledging errors,
for example if no keyboard is connected.
Floppy check The floppy head is stepped inward and then back to its original position
during the system run-up phase. This test is useful because it reinitiali-
zes the drive.
Summary
screen
The most important system parameters are displayed when the system
run-up phase completes.
’Enabled’ means that the feature is active. ’Disabled’ means that the feature is
inactive.
