Technical data
SIMATIC RF120C
34 Operating Instructions, 02/2021, C79000-G8976-C328-03
6GT2002-0LA00
Mechanical specifications
Material
Xantar MX 1094
Color
Ti-Grey 24L01
Dimensions (W x H x D)
30 x 100 x 75 mm
Weight
0.15 kg
Type of mounting
S7-1200 module rack
Maximum tightening torque of
the screw for securing the equipment
0.45 Nm
Environmental conditions
Ambient temperature
• during operation (horizontal installation) • 0 ... +55 °C
• during operation (vertical installation) • 0 ... +45 °C
• During transport and storage • -40 ... +70 °C
Degree of protection
IP20
Shock resistance
to IEC 61131-2
Shock acceleration
300 m/s²
Vibration acceleration
100 m/s²
Product functions
LED display
4 LEDs for reader connection,
1 LED for device status
Function blocks SIMATIC S7-1200 and S7-1500
Library with function blocks:
Read, Write, Read_EPC-ID, Write_EPC-ID, Set_Ant,
Reset_Reader, AdvancedCmd
Transponder addressing
Direct access via addresses
Communications protocol
S7 communication
Commands
Initialize transponder,
Read data from transponder,
Write data to transponder, etc.
Standards, specifications, approvals
Approvals
CE, FCC, cULus (File E85972), KCC, C-Tick
MTBF (at 40°C)
196 years
1)
All supply and signal voltages must be safety extra low voltage (SELV/PELV according to EN 60950)
24 V DC supply: Safety (electrical) isolation of low voltage (SELV / PELV acc. to EN 60950)
2)
The power supply must provide the required current of max. 1 A during brief power outages of ≤
20 ms.
