Page #54 background imageLoading...
Page #54 background image
Appendix
A.4 Ordering data
SIMATIC RF120C
54 Operating Instructions, 02/2021, C79000-G8976-C328-03
A.4 Ordering data
A.4.1 Ordering data for RF120C
Table A- 5 Ordering data
Article number
RF120C communications module
6GT2002-0LA00
Table A- 6 Ordering data - Accessories
Article number
Connecting cable D-sub (RS422) ↔ M12;
for RF200/RF300, MV400/MV500
2 m
6GT2091-4LH20
5 m
6GT2091-4LH50
10 m
6GT2091-4LN10
CM adapter cable
for MV500 (M12, 12-pin ↔ M12, 8-pin)
0.5 m
6GF3500-8BA11
5 m
6GF3500-8BA12
Connecting cable D-sub (RS232) ↔ 5-pole bush hous-
ing (PicoBlade);
for RF1000
2 m
6GT2891-6UH20
Connecting cable D-sub (RS232) ↔ RJ50
for MV320
cable is coiled and can be extended up to 4.0 m
1.6 m
6GT2191-1BH50
Extension cable M12 M12
for RF200/RF300, MV400
2 m
6GT2891-4FH20
5 m
6GT2891-4FH50
10 m
6GT2891-4FN10
20 m
6GT2891-4FN20
50 m
6GT2891-4FN50
Extension cable M12 M12;
for RF200/RF300, MV400
connector angled on reader side
2 m
6GT2891-4JH20
5 m
6GT2891-4JH50
10 m
6GT2891-4JN50
Connecting cable M12 ↔ Sub-D;
for MOBY D
only in combination with the connecting cable D-sub
(RS422) ↔ M12
2 m
6GT2691-4FH20
Connecting cable M12 ↔ ES175201;
for MOBY U
only in combination with the connecting cable D-sub
(RS422) ↔ M12
2 m
6GT2091-4FH20
5 m
6GT2091-4FH50
Terminal block (5 units)
3-pin terminal block for power supply for S7-1200 CPs
6GK5980-1CB00-0DA5
