Appendix
A.1 Certificates & approvals
SIMATIC RF120C
42 Operating Instructions, 02/2021, C79000-G8976-C328-03
FM
The product meets the requirements of the standards:
• Factory Mutual Approval Standard Class Number 3611
• FM Hazardous (Classified) Location Electrical Equipment:
Non Incendive / Class I / Division 2 / Groups A,B,C,D / T4 and
Non Incendive / Class I / Zone 2 / Group IIC / T4
A.1.2 Standards and test regulations
Industrial environments
The product was developed for use in industrial environments.
Requirements for emissions
Requirements for immunity
Electromagnetic compatibility (EMC)
The electromagnetic compatibility (EMC) of an electrical device is its capability of functioning
as intended in an electromagnetic environment without emitting electromagnetic
interference that could impair the operation of other electrical devices in the vicinity.
Table A- 1 Electromagnetic compatibility
EN 61000-4-2
Electrostatic discharge
8 kV air discharge to all surfaces
4 kV contact discharge to exposed conductive surfaces
Radiated electromagnetic field
80 ... 1 000 MHz, 10 V/m, 80% AM at 1 kHz
1.4 ... 2.0 GHz, 3 V/m, 80% AM at 1 kHz
2.0 ... 2.7 GHz, 1 V/m, 80% AM at 1 kHz
EN 61000-4-4
Fast transient bursts
2 kV, 5 kHz with coupling network to AC and DC system power
1 kV, 5 kHz with coupling clamp to inputs/outputs
Surge immunity
DC systems - 2 kV common mode, 1 kV push-pull
For DC systems (I/O signals, DC power supplies), external protection is
EN 61000-4-6
Conducted disturbances
150 kHz to 80 MHz, 10 V RMS, 80 % AM at 1 kHz
EN 61000-6-4, class A
0.15 MHz to 5 MHz
< 79 dB (μV) quasi peak; <66 dB (μV) average
< 73 dB (μV) quasi peak; <60 dB (μV) average
EN 61000-6-4, class A
30 MHz to 230 MHz
< 40 dB (μV/m) quasi peak; measured at 10 m
< 47 dB (μV/m) quasi peak; measured at a distance of 10 m
