Overview
1.3 Exterior design
IFP Basic
10 Operating Instructions, 03/2019, A5E46178354 - AB
Rear view
①
Rating plate
②
Holes for VESA mounting
③
Recesses for mounting clips
1.3.2
Interfaces
①
X80 connector for 24 VDC power supply
②
X72 VGA interface
③
X71 DisplayPort interface
④
X61, X62 USB 2.0 Type A
⑤
X60 USB 2.0 Type B
