Installing and connecting the device
3.3 Connecting the device
IFP Basic
Operating Instructions, 03/2019, A5E46178354 - AB
35
Connecting IFP Basic to a PC
Connection diagram
Ensure you have the following articles before connecting the IFP Basic.
Note
When VGA port and DP port are connected to two hosts, IFP displays the signals from DP
port.
● VGA/DisplayPort cable
● USB cable (type B to type A)
● Power cable
● PC
Connect the Flat Panel and the PC using a VGA or DisplayPort
line.
Connect the device and the PC with a USB line (type A to type B).
