Siemens SIMATIC IFP Basic Series

Installing and connecting the device
3.3 Connecting the device
IFP Basic
30 Operating Instructions, 03/2019, A5E46178354 - AB
Secure the device to the mounting interface with four M4 x 10 screws.
3.3
Connecting the device
3.3.1
Notes on connection
Requirement
● The device has been installed according to the information provided in these operating
instructions.
Connecting cables
CAUTION
Use copper cables at connectors with terminal connections
Use copper (Cu) cables for all supply lines that are connected to the device with terminals,
e.g. 24 VDC power supply cables to the 24 VDC power supply connectors.
Utiliser des câbles en cuivre sur les connexions à bornes
Utilisez des câbles en cuivre (Cu) pour tous les câbles d'alimentation qui sont raccordés à
l'appareil par des bornes, par exemple les câbles d'alimentation 24 V CC sur le connecteur
d'alimentation 24 V CC.
