Installing and connecting the device
3.1 Preparing for installation
IFP Basic
Operating Instructions, 03/2019, A5E46178354 - AB
21
Permitted mounting positions
The device may be mounted in the following positions:
● Standard position: horizontal
● Inclined installation in horizontal format with a vertical inclination of maximum ±45 °
For horizontal installation, the following ambient temperatures are permitted:
Maximum ambient temperature at the
device
45 °C (IFP1200 Basic, IFP1500
Basic, IFP1900 Basic)
The device enclosure fulfills the requirement of a fire
protection enclosure.
