Siemens SIMATIC IFP Basic Series

Technical information
7.5 Technical specifications
IFP Basic
Operating Instructions, 03/2019, A5E46178354 - AB
59
SIMATIC IFP1200
Basic
SIMATIC IFP1500
Basic
SIMATIC IFP1900
Basic
SIMATIC IFP2200
Basic
Backlighting
Half Brightness Life
Time (MTBF
1
)
LED
50000 h
LED
30000 h
Pixel error class in
accordance with
ISO 9241-307
II
1
MTBF: Operating hours after which the maximum screen brightness is reduced by half compared to the original value.
MTBF is increased by using the integrated dimming function, for example time-controlled via screen saver or centrally
via PROFIenergy.
Input device
SIMATIC IFP1200 / IFP1500 / IFP1900 / IFP2200 Basic
Keyboard
Externally via USB
Touch screen
Analog resistive single touch screen
Interfaces
USB Type A, rear
USB Type B, rear
DisplayPort
VGA
IFP1200 / IFP1500 / IFP1900 /
IPF2200 Basic
2 1 1 1
1
USB type A, maximum load 500 mA, equivalent to USB standard 2.0
DC power supply
SIMATIC IFP1200 Basic
SIMATIC IFP1500 Basic
SIMATIC
IFP1900
Basic
SIMATIC IFP2200
Basic
Rated voltage
Permitted voltage range
24 V DC
+20.4 V to + 28.8 V
Inrush current I
2
t
Maximum 2.5 A, 15 ms
Power consumption
1
13 W
17 W
19 W
24 W
Maximum permitted transients
35 V (500 ms)
Minimum time between two tran-
sients
50 s
Internal protection Electronic
1
The power loss generally corresponds to the specified value for power consumption.
