Installing and connecting the device
3.2 Installing the device
SIMATIC IPC BX-39A
Operating Instructions, 07/2022, A5E50715883-AA
33
Instructions for wall mounting
Use the following fasteners:
• Mounting onto DIN rail
Material
Hole diameter
Fastener
Metal,
min. 2 mm thick
5 mm
• 2 x M4 screws
• 2 x M4 nuts
Concrete
6 mm, 40 mm deep
• 4 x dowels, ∅ 6 mm, 40 mm length
•
4 x screws, ∅ 4 mm, 40 mm length
Plasterboard,
min. 13 mm thickness
14 mm
4 x toggle bolts, ∅ 4 mm, 50 mm length
• Wall mounting
Material
Hole diameter
Fastener
Concrete
6 mm, 40 mm deep
• 4 x dowels, ∅ 6 mm, 40 mm length
• 4 x screws, ∅ 4 mm, 40 mm length
Plasterboard,
min. 13 mm thickness
14 mm
4 x toggle bolts, ∅ 4 mm, 50 mm length
• Vertical mounting
Material
Hole diameter
Fastener
Concrete
6 mm, 40 mm deep
8 mm, 40 mm deep
• 4 x dowels, ∅ 6 mm, 40 mm length
• 4 x screws, ∅ 4 mm, 40 mm length
• Dowel, ∅ 8 mm, 40 mm length
•
Screw, ∅ 5 mm, 40 mm length
Plasterboard,
min. 13 mm thickness
14 mm
Toggle bolt, ∅ 4 mm, 50 mm length
