Technical specifications
8.6 Technical specifications of the drives
SIMATIC IPC BX-39A
80 Operating Instructions, 07/2022, A5E50715883-AA
8.6 Technical specifications of the drives
See the note in "Applicability of technical specifications (Page 74)".
SSD
M.2 NVMe SSD >= 256 GB, form factor 22 mm x 30 mm, type M
8.7 Technical specifications of the motherboard
See the note in "Applicability of technical specifications (Page 74)".
Chipset
Intel® RM590E
Processor
• Intel® Celeron® 6600HLE 2 cores/2 threads,
2.1 GHz, 8 MB cache, ECC, TCC
• Intel® Xeon® W-11155MLE 4 cores/8 threads, 1.8 (3.1) GHz,
8 MB cache, ECC, TCC
• Intel® Xeon® W-11555MLE 6 cores/12 threads, 1.9 (4.4) GHz,
12 MB cache, vPro (iAMT), ECC, TCC
• Intel® Xeon® W-11865MLE 8 cores/16 threads, 1.5 (4.5) GHz,
24 MB cache, vPro (iAMT), ECC, TCC
Main memory
4 up to 32 GB, DDR4 SDRAM, SODIMM
see ordering documents for features
Buffer memory
512 KB NVRAM
Expansion slots IPC BX-39A
Version
• without expansion slots
• with 1 expansion slot
or
•
with 2 expansion slots
Maximum bandwidth of PCI slots
Slot 1: Rev. 4.0: 16 GT/s (1969 Mbps) bandwidth per lane
Slot 2: Rev. 3.0: 8 GT/s (985 Mbps) bandwidth per lane
Max. permissible power loss per
slot
Total power consumption (all voltages) must not exceed 8 W. The
total power for both PCIe slots must not exceed 12 W.
Expansion card slots
Slots for expansion cards IPC BX-39A with one expansion slot
(Bus board 1 x PCIe)
Slot 1
PCI Express x4 (mechanical x8): Specification Rev. 4.0, length: Max. 175 mm
Expansion card slots IPC BX-39A with two expansion slots
(Bus board 2 x PCIe)
Slot 1
PCI Express x4 (mechanical x8): Specification Rev. 4.0, length: Max. 175 mm
Slot 2
PCI Express x1 (mechanical x4): Specification Rev. 3.0, length: Max. 175 mm
