SIMATIC IPC BX-39A
74 Operating Instructions, 07/2022, A5E50715883-AA
Technical specifications
8
8.1 Applicability of technical specifications
Note
The following technical specifications only apply under the following conditions:
•
The device is in good working order.
•
The device is closed.
•
The I/O devices fulfill the requirements for the respective area of application (interference
emission according to EN 61000-6-3 / IEC 61000-6-3, interference immunity according to
EN 61000-6-2 / IEC 61000-6-2).
8.2 General technical specifications
See the note under "Validity of the technical specifications (Page 74)".
Article number
6AG4142-.....-.... (for details, refer to the ordering documenta-
tion)
Dimensions
Base device:
Device with 2x expansion:
262 x 133 x 63 (W × H × D in mm)
262 x 133 x 114 (W × H × D in mm)
Weight
Base device:
Device with 2x expansion:
Approx. 2.3 kg
Approx. 2.7 kg
Supply voltage DC
1
Nominal 24 V DC (-20% / + 20%), SELV
1
Input current DC
Continuous current up to 4 A
Short-term voltage interruption in
accordance with Namur
Max. 20 ms (at 20.4 V)
(max. 10 events per hour; recovery time of at least 1 s)
Max. power consumption
67.5 W (at 24 V)
Noise emission
< 40 dB(A) according to DIN 45635-1
Degree of protection
IP 20 according to IEC 60529
2
Quality assurance
In accordance with ISO 9001
