Hardware description
A.3 Bus board
SIMATIC IPC BX-39A
96 Operating Instructions, 07/2022, A5E50715883-AA
A.3 Bus board
A.3.1 Expansion card slots on the bus board
The bus board is designed as a link between the motherboard and the expansion cards.
The bus board is available in the following designs:
Variant 1 (1 slot)
Slot X110 PCI Express x4 (mechanical x8)
Power supply connection; see Pin assignment power supply connection for expansion cards
(Page 97)
