Expanding and assigning parameters to the device
6.6 Drives
SIMATIC IPC BX-39A
Operating Instructions, 07/2022, A5E50715883-AA
67
Procedure - Option 2
1.
Loosen the screw of the removable
Slider with the Torx
T10 type screw-
driver.
2.
Remove the cover from the device and
place it on the side.
3.
Pull out the Slider in the direction of the
arrow using the lug.
4.
Place the Slider on a suitable surface.
5.
Remove the marked screws with the
screwdriver of type Torx
T8.
