Technical specifications
8.4 Technical specifications
SIMATIC IPC627D/827D
114 Operating Instructions, 09/2014, A5E32990859-AB
Electromagnetic compatibility
Interference emission
EN 61000-6-3, EN 61000-6-4, CISPR22 class B; FCC class A
Immunity with regard to conduct-
ed interference on the supply lines
± 2 kV according to IEC 61000-4-4; burst
± 1 kV according to IEC 61000-4-5; symmetrical surge
± 2 kV according to IEC 61000-4-5; asymmetrical surge
Noise immunity on signal lines ± 1 kV to IEC 61000-4-4; Burst; Length < 3 m
± 2 kV in accordance with IEC 61000-4-4; Burst; length > 3 m
± 2 kV in accordance with IEC 61000-4-5; Surge; length > 30 m
Immunity to electrostatic dis-
charge
± 6 kV contact discharge in accordance with IEC 61000-4-2
± 8 kV air discharge in accordance with IEC 61000-4-2
Immunity to RF interference 10 V/m 80 MHz–2 GHz, 80% AM according to IEC 61000-4-3
3 V/m 2–2.7 GHz, 80% AM according to IEC 61000-4-3
10 V 10 KHz–80 MHz, 80% AM according to IEC 61000-4-6
Immunity to magnetic fields
100 A/m, 50/60 Hz according to IEC 61000-4-8
Motherboard
Chipset
Intel DH82C226 PCH
Processor
• Intel Xeon E3-1268L v3 2.3 (3.3) GHz, 4 cores, 8 threads,
GT2, 8 MB second-level cache, AMT
• Intel Core i3-4330TE 2.4 GHz, 2 cores, 4 threads, GT2, 3 MB
second-level cache, AMT
• Intel Celeron G1820TE 2.2 GHz, 2 cores, 2 threads, GT1,
2 MB second-level cache
Main memory Expansion options:
• 2048/4096/8192/16384 MB without ECC
• 4096/8192/16384 MB with ECC
Buffer memory
2 MB SRAM
Expansion slots IPC627D
Maximum 2 expansion slots
Expansion slots IPC827D
Maximum 5 expansion slots
Maximum bandwidth of PCI slots
Rev. 2.2: 133 Mbps
Maximum bandwidth of PCI slots Rev. 2.0: 5 GT/s (500 Mbps) bandwidth per lane
Rev. 3.0: 8 GT/s (985 Mbps) bandwidth per lane
Max. accumulated power loss
per slot
Total power consumption (all voltages) may not exceed 25 W.
