Installing and connecting the device
3.1 Preparing for installation
SIMATIC IPC627D/827D
26 Operating Instructions, 09/2014, A5E32990859-AB
Microsoft Windows "Product Key" on the "Certificate of Authenticity" (COA):
The COA label is only attached to the rear of the device containing a Windows Embedded
Standard 7 or Windows 7 operating system.
● COA label of a device with Windows Embedded Standard 7 operating system
● COA label of a device with Windows 7 operating system
Permitted mounting positions
Mounting positions according to UL60950-1/UL508/EN60950-1/CSA22.2 No. 60950-1
Points to note with expansion cards
Expansion cards may impose restrictions on the installation location (fire-proof enclosure)
and permitted mounting positions (see Technical specifications). If the device has been
fitted with expansion cards, please observe the safety and installation instructions for the
expansion cards in the corresponding documentation.
If in doubt, install the device in an enclosure that is compliant with
IEC/UL/EN/DIN-EN 60950-1, sections 4.6 and 4.7.3.
Operation only in closed rooms
The device is only approved for operation in closed rooms. Pay attention to the ambient
and environmental conditions.
