Siemens SIMATIC IPC627D User Manual

Expanding and assigning parameters to the device
6.4 Drives
SIMATIC IPC627D/827D
68 Operating Instructions, 09/2014, A5E32990859-AB
Removing 3.5" drive
Note
Special screws with inch threads (screw designation 6
-32x3/16''-St-G3E) are used with this
drive.
1.
Remove the drive bay module.
2.
Disconnect the power supply and the data cable from the drive.
3.
Remove the screws ①
(Torx
T15) of the drive.
4.
Remove the hard disk drive from the bay.
Removing hard disk in removable drive bay
See chapter "Maintaining and repairing the device", "Removing and installing hardware",
section "Removing and installing the hard disk in the removable drive bay (Page 81)".
Installation
Proceed in reverse order in each case.
