Technical data
11.1 Technical specifications of SIMATIC MV500
SIMATIC MV500
196 Operating Instructions, 05/2019, C79000-G8976-C494-02
6GF3540-0xx10
6GF3550-0xx10
Operating distance
• Mini lens:
70 ... 3000 mm
1)
• EF lens:
Depending on the lens used
2)
Mounting type of lens
C-mount lens connection
Type of light source
Built-in ring lights or external ring lights
Image acquisition frequency (max.)
• Device version S: 100 Hz
• Device version H: 33 Hz
Type of focusing
• Mini-lens: Manual adjustment on the lens
• EF lens: Automatic setting via WBM
Supply voltage, current consumption, power loss
Supply voltage
24 V DC (20.4 to 28.8 V DC)
Current consumption (at 24 V DC)
• Typical • 0.2 A
• 0.4 A with ring light (continuous light)
• Maximum • 2.0 A
Mechanical specifications
Housing
• Material • Die-cast aluminum (silicone-free)
• Color • TI-Grey
Permitted ambient conditions
Ambient temperature
• During operation • 0 … +50 °C
• During transportation and storage • -30 … +70 °C
Relative humidity (max.)
95%
Degree of protection
IP67 according to IEC 60529
Shock resistance
IEC 60068-2
Shock acceleration
300 m/s²
Vibration acceleration
40 m/s²
Design, dimensions and weight
Dimensions (W × H × D)
68 × 122 × 45 mm
Weight
0.55 kg
Type of mounting
4 x M4 screws
LED display design 7 LEDs
