Scope of delivery and ordering data
13.3 Accessories
SIMATIC MV500
Operating Instructions, 05/2019, C79000-G8976-C494-02
213
13.3.4 Protective lens barrel
The following protective lens barrel is compatible with all lenses and ring lights mentioned in
this manual. Note that when using the 75 mm (6GF9001-1BK01) mini lens, you need an
additional protective lens barrel extension.
Table 13- 8 Protective lens barrel for built-in ring lights for SIMATIC MV500
Protective lens barrel (glass)
for SIMATIC MV500
• Degree of protection: IP67
• Front pane: Glass
• Dimensions (∅ × L): 65 × 65 mm
• Inner diameter: 60.4 mm
• Max. lens length
with built-in ring light: 44.7 mm
without built-in ring light: 47.9 mm
• Suitable for filters
M58 × 0.75; with IP67
6GF3540-8AC11
Table 13- 9 Protective lens barrel extension for built-in ring lights for SIMATIC MV500
Protective lens barrel extension
Protective lens barrel extension
for SIMATIC MV500
• Degree of protection: IP67
• Dimensions (∅ × L): 65 × 48 mm
• Inner diameter: 57 mm
• Effective protective lens barrel exten-
sion: 35 mm
6GF3440-8AC13
13.3.5 PoE switches for power supply
The following PoE switches are suitable for powering the SIMATIC MV500 optical readers
via the Ethernet cable.
Table 13- 10 PoE switches
SCALANCE XP208 POE EEC 6GK5208-0UA00-5ES6
