SIMATIC MV500
Operating Instructions, 05/2019, C79000-G8976-C494-02
195
Technical data
11
11.1 Technical specifications of SIMATIC MV500
Table 11- 1 Technical specifications of the SIMATIC MV500 optical reader
6GF3540-0xx10
6GF3550-0xx10
Product type designation SIMATIC MV540 S
SIMATIC MV540 H
SIMATIC MV550 S
SIMATIC MV550 H
Suitability
Suitability in use 1D codes: Int. 2/5, Code 128, Code 93, Code 39,
Code 32, Codebar, EAN 13, EAN 8, UPC-A,
UPC-E, GS1, Pharmacode, Postnet, 2D codes:
DMC, dot code, PDF417 (without: Truncated,
Micro and Macro), QR (without: Micro and Macro)
Interfaces
Combination interface Power supply, DI/DQ, RS232 and CM
(M12, 12-pin)
Ethernet interface Power over Ethernet
(M12, 4-pin)
Number of digital inputs
1
Number of digital outputs
3
Design of digital inputs
1 fast trigger input
Design of digital outputs 1 high-speed strobe output for external lighting,
2 isolated outputs, short-circuit-proof, max. 100
mA,
Optical data
Design of image sensor/camera
• Device version S:
CMOS 0.5 Megapixel; 800 × 600
• Device version H:
CMOS 1.3 Megapixel; 1280 × 1024
Type of image capture Global shutter with manual or automatic exposure
time
