Scope of delivery and ordering data
13.3 Accessories
SIMATIC MV500
210 Operating Instructions, 05/2019, C79000-G8976-C494-02
Table 13- 3 EF lenses for SIMATIC MV500
EF lens 25 mm
• Aperture and focus adjustable
• Aperture: 5.5
• Reading range: 200 to 2000 mm
• Dimensions (∅ × L): 27.4 × 28.1 mm
6GF3540-8EA03-
0LL0
13.3.2 Built-in ring lights
Note
Achievement of IP67 protection
To achieve IP67 degree of protection, a protective lens barrel must be screwed on and all
interfaces must be closed by cable connections or protective caps.
If no protective lens barrel is used or the interfaces are closed, the reader only achieves IP20
degree of protection.
Note
Compatibility of the built-in ring lights for SIMATIC MV440
Note that SIMATIC MV440 built-in ring lights are compatible with SIMATIC MV500 optical
readers. However, using the MV440 built-in ring lights on MV500 does not support the micro
SD card and E-focus function.
