Cellular Modem Modules
6.3RUGGEDCOM RX1500PN LM W21
Supported WCDMA Frequency Bands
Frequency RangeBand
Tx (MHz) VSWR Rx (MHz) VSWR
Band I
WCDMA 2100
1920 to 1980 < 2.5:1 2110 to 2170 < 3.5:1
Band II
WCDMA 1900
1850 to 1910 < 2.5:1 1930 to 1990 < 2.5:1
Band VIII
WCDMA 900
880 to 915 < 2.5:1 925 to 960 < 3.5:1
Band V
WCDMA 850
824 to 849 < 2.5:1 869 to 894 < 3.5:1
Band VI
WCDMA 800
830 to 840 < 2.5:1 875 to 885 < 3.5:1
GSM 850 824 to 849 < 2.5:1 869 to 894 < 3.5:1
EGSM 900 880 to 915 < 2.5:1 925 to 960 < 3.5:1
GSM 1800 1710 to 1785 < 2.5:1 1805 to 1880 < 3.5:1
GSM 1900 1850 to 1910 < 2.5:1 1930 to 1990 < 2.5:1
RX Diversity Support and Maximum Allowable Gain per WCDMA Frequency Band
Band RX Diversity Support Maximum Allowable Gain (dBi)
Band I WCDMA 2100
ü
4
Band II WCDMA 1900
ü
4
Band VIII WCDMA 900
ü
5
Band V WCDMA 850
ü
5
Band VI WCDMA 800
ü
5
GSM 850
û
5
EGSM 900
û
5
GSM 1800
û
4
GSM 1900
û
4
Operating Temperature
Operating Temperature Compliance
-30 to 60 °C (-22 to 140 °F) Full Radio Frequency (RF) compliance
60 to 75 °C (140 to 167 °F) Reduced Radio Frequency (RF) performance
Certification
This module has been certified to comply with the requirements of the following
standards.
Certification Details
Verizon Wireless This module is certified by Verizon Wireless in North America under
Open Development Certification Agreement MA-004198-2012.
RoHS This module is declared by Siemens AG to meet the requirements of
the following RoHS (Restriction of Hazardous Substances) directives
