Copper Ethernet Modules
3.10RUGGEDCOM RX1500PN LM 6TX01
NamePin
10/100Base-TX 1000Base-TX
Description
1 RX+ BI_DA+ Receive Data+ or Bi-
Directional Pair A+
2 RX- BI_DA- Receive Data- or Bi-
Directional Pair A-
3 TX+ BI_DB+ Transmit Data+ or Bi-
Directional Pair B+
4 Reserved (Do Not Connect) BI_DC+ Transmit Data+ or Bi-
Directional Pair C+
5 Reserved (Do Not Connect) BI_DC- Receive Data- or Bi-
Directional Pair C-
6 TX- BI_DB- Transmit Data- or Bi-
Directional Pair B-
7 Reserved (Do Not Connect) BI_DD+ Receive Data- or Bi-
Directional Pair D+
8 Reserved (Do Not Connect) BI_DD- Receive Data- or Bi-
Directional Pair D-
Technical Specifications
General Power Consumption 5 W
Connector RJ45
Speed 100 Mbps
Interface TX
Duplex FDX/HDX
Cable Type > CAT-5
Wiring Standard TIA/EIA T568A/B
Maximum Distance 100 m (328 ft)
Interface/Cable
Isolation 1.5 kV
Operating Temperature -40 to 85 °C (-40 to 185 °F)
Operating Relative Humidity 5 to 95% (non-condensing)
Environment
Storage Temperature -40 to 85 °C (-40 to 185 °F)
Certification
This module has been certified to comply with the requirements of the following
standards.
Certification Details
RoHS This module is declared by Siemens AG to meet the requirements of
the following RoHS (Restriction of Hazardous Substances) directives
for the restricted use of certain hazardous substances in electrical
and electronic equipment:
• China RoHS 2
Administrative Measure on the Control of Pollution Caused by
Electronic Information Products
66
RUGGEDCOM Modules
Catalog, 07/2021, C79000-G8976-1320-16
