5 Configuring Communication Connections
A-159
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
Parameter Description
Via CP / Local If more than one Ethernet CP exists in the station via which connections operated you
can select route here.
The CPs are only displayed for selection if they are networked.
If no CP is assigned (for example because the CP was deleted previously) “(None)” is
displayed here.
If there is only one CP plugged into the station, no selection is possible.
Via CP /
Partner
(remote)
Depending on the local selection, the possible remote CPs are displayed. All the CPs
connected to the same subnet (networked) and the local CP can be selected.
Alternatives are only available when a connection is established to a remote station
configured in the same project and the remote station has two or more CPs.
If there is no CP assigned on the partner (for example because the CP was deleted
previously) “None” is displayed here.
If there is only one CP in the remote station, no selection is possible.
If the partner is an “other station” or SIMATIC S5 PLC, one or more attachments are
displayed for selection depending on the configuration and networking of the station.

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
