3 Operating the Ethernet CP with
A-58
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
3.1 How to Commission an Ethernet CP
The essential steps in commissioning an Ethernet CP are shown in the following
overview:
Notice
The chart below shows the basic steps. Please read the device-specific
instructions in “Installation and Commissioning” in the description of your CP
(Manual Part B).
Install the CP on the S7 standard rail
(S7-300) or in the S7 rack (S7-400).
Connect the power supply.
Connect the CP to Industrial Ethernet.
Install the STEP 7 configuration
software on a PG/PC.
Configure the Ethernet CP:
 by configuring in the
project engineering
see Section 3.3
or
 by programming
see Section6
Turn on the S7 station.
Download the configuration data and the user programs to
the S7 station and/or CP.
Use the diagnostic functions during commissioning
and to analyze problems.
Configuring / ProgrammingInstallation and Commissioning
S7 - 300 / 400

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
