5 Configuring Communication Connections
A-100
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
5.1 Procedure
Initial Situation
The steps described here assume the following:
1. You have created the local S7 station and the required partner stations in your
STEP 7 projects (refer to the description in Chapter 3).
2. You have clarified the other station types with which connections must be
established. You create substitute objects for these station types in your
STEP 7 projects.
Setting up Connections and Using Them in the User Program
The following steps are necessary to operate connections on the SIMATIC S7 PLC
with the Ethernet CP:
Program the SEND/RECEIVE
interface in the user program.
(Refer to Section 4.2 and the detailed
FC description in Chapter 7).
Programming
Create new connections.
(see Section 5.3.1)
Download connection configurations
and user programs to the S7 station.
Configure connection properties.
(see Sections 5.4 to 5.4)
Configuring
necessary steps
optional steps
Legend:
