4.2 Programming the SEND/RECEIVE Interface
Principle of Job and Data Transfer
The user program triggers the transfer of the user data areas with FC calls and
monitors the transfer by evaluating the return codes of the FCs.
The following parameters are transferred when the FCs are called:
 The number of the connection (ID)
 The location of the user data area in the CPU
For detailed information about the call interface see Chapter 7.
Purpose of the FCs
Calling the function blocks has the following effects:
 The user data area is transferred to the Ethernet CP or received from the
Ethernet CP.
 The execution of the job is confirmed positively or negatively in a status
message.
Procedure
Program the SEND/RECEIVE interface in the user program as follows:
1. Use the following functions (FCs) for data transmission on connections:
- AG_SEND / AG_LSEND for transferring the user data area to the Ethernet
CP
- AG_RECV / AG_LRECV for entering data received from the Ethernet CP in
the user data area
2. Evaluate the following bits in the FCs:
- for AG_SEND / AG_LSEND the parameters DONE, ERROR, STATUS
- for AG_RECV / AG_LRECV the parameters NDR, ERROR, STATUS
Notice
Connection numbers (IDs) must be taken from the configuration when
programming.
To ensure correct parameter settings for the block calls, The LAD/STL/FBD editor
in STEP 7 provides you with the option of accepting all the relevant parameters
from the hardware configuration (HW Config) and from the connection
configuration. For more information, refer to Section 7.2

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
