Siemens SIMATIC NET S7-300 User Manual

9 Firmware Loader
A-283
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
9.1 Application
Firmware
Here, firmware means the system programs in the SIMATIC NET modules.
Uses of the Firmware Loader
The Firmware Loader allows you to download more recent firmware versions to the
SIMATIC NET modules. It is used on the following:
 PROFIBUS modules
 Industrial Ethernet modules
 Modules for Gateways (for example, IE/PB Link)
Installation
The firmware loader is available when you have installed NCM S7 on your PG/PC.
Load Files
The Firmware Loader supports the following file types:
 <file>.FWL
A file form that contains extra information that can be displayed in the dialogs of
the firmware loader in addition to the information of the LAD file form. Based on
this information, the firmware loader can check the firmware for compatibility
with the device.
For detailed information, read the documentation, for example, the README file
shipped with the load file.
This information is displayed even after reading in the FWL file into the firmware
loader.
Working with the Firmware Loader
Depending on the module type, the downloading is prepared and executed in three
or four steps.
For more detailed information, refer to the next section and the dialog boxes
themselves.

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
