Siemens SIMATIC NET S7-300 User Manual

A-99
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
5 Configuring Communication Connections
This chapter explains the following:
 The general aspects of configuring communication connections
 How to configure ISO transport, ISO-on-TCP, UDP and TCP connections
 How to use the connection configuration functions to specify communication
partners that exchange data via UDP
You will find a description of the connection-specific properties dialogs in the
following sections:
 ISO transport connections see Section 5.4
 ISO-on-TCP connections see Section 5.5
 TCP connections see Section 5.6
 UDP see Section 5.7
You will find further information in the following sources:
 For the properties of the configurable connection types, refer to Section 1.5
 There are situations in which communication connections are not set up over
the configuration interface of STEP 7 but program-controlled by certain
applications; see also Chapter 6.
 For the properties of the configurable connection type E-mail, refer to /5/.
 You will find information on the numbers of connections and amounts of data in
Section 4.1.
 For information on configuring connections, refer to the online help of STEP 7
by selecting Help

Contents.

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
