Siemens SIMATIC NET S7-300 User Manual

7 Programming FCs (Functions) and FBs for S7 Ethernet CPs
A-222
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
RESULT (for CMD = 1) Meaning
Parameter
Meaning
Bit/valu
e
Hex value/range
RESULT1 0000 *000
H
Bits 12-15: General CP information
(excluded values: 0x3,0xB)
Bit 12 +
13
Information on connection status:
(only available for SEND/RECV
connections based on the ISO/RFC/TCP
protocols, with UDP, the corresponding
internal information is output)
00  Connection is terminated
01  Connection establishment active
10  Connection termination active
11  Connection is established
Bit 14 CP information:
0  CP in STOP
1  CP in Run
Bit 15 Reset ID
0  FC10 has not yet reset a connection or
the reset ID was cleared.
1  The control block has executed a
connection reset.
RESULT1 **** 0000
H
Bits 16-31: Reserved
0 – reserved for later expansions
RESULT2 0000 0000
H
- reserved for later expansions
FC10 AG_CNTRL - continued

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
