7 Programming FCs (Functions) and FBs for S7 Ethernet CPs
A-221
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
RESULT (for CMD = 1) Meaning
Parameter
Meaning
Bit/valu
e
Hex value/range
RESULT1 0000 00*0
H
Bits 4-7: Codes for the receive direction
(excluded values: 0x2)
Bit 4 Connection Type
0  No send and receive connection
1  Connection reserved for send and
receive jobs
Bit 5 Status of current job
0  No receive job being executed
1  Receive job being executed
Bits 6+7 Previous job:
00  No information available on previous
receive job
01  Previous receive job completed
successfully
10  Previous receive job not completed
successfully
RESULT1 0000 0*00
H
Bits 8-11: Codes for FETCH/WRITE
(excluded values: 0x3,0x7,0x8,0xB,0xF)
Bit 8 Connection type:
0  No FETCH connection
1  Connection reserved for FETCH jobs
Bit 9 Connection type:
0  No WRITE connection
1  Connection reserved for WRITE jobs
Bit 10 Job status (FETCH/WRITE):
0  Job status OK
1  Job status NOT OK
This ID is set in the following situations:
- The job was acknowledged
negatively by the CPU
- The job could not be forwarded to
the CPU because the connection
was in the “LOCKED” status.
- The job was rejected because the
FETCH/WRITE header did not have
the correct structure.
Bit 11 Status of FETCH/WRITE job
0  No job active
1  Job from LAN active
FC10 AG_CNTRL - continued
