6 Programmed Communication Connections
A-170
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
6.5 Parameter Fields for Connection Types
General
Below, you will see which values need to be entered in the parameter fields and
which subfields are used for the various connection types.
Some applications do not require all the subfield types - refer once again to the
table for details.
Note
Please read the explanations of the configurable connection properties for the
individual connection type in Chapter 5!
Connection ID
The ID parameter that precedes each connection parameter field beside the type
ID is particularly important.
On programmed connections, you can assign this ID freely within the permitted
range of values. You must then use this ID on the call interface of the FCs for the
SEND/RECV interface to identify the connection.
Range of values for the connection ID:
 S7-400: 1,2 through 64
 S7-300: 1,2 through 16

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
