7 Programming FCs (Functions) and FBs for S7 Ethernet CPs

A-184

S7-CPs for Industrial Ethernet Configuring and Commissioning

Release 01/2007

C79000-G8976-C182-07

Notice

Please remember that if you replace a module, you must only use the blocks

permitted for the configured CP type in the user program.

This means:

 If you replace the module without adapting the configuration data to the

possibly newer module type, you do not need to make any changes to the

blocks used.

 If you replace the module and you do adapt the configuration data to the newer

module type, you must use the block versions approved for this module type.

We recommend that you always use the latest block versions for all module types.

With the older module types, this recommendation assumes that you are using the

latest firmware for the particular block type.

You will find more information on replacing blocks in our Customer Support on the

Internet.

The manuals for specific devices /2/ contain information on the compatibility of the

S7-CPs and the corresponding blocks (FCs / FBs).
