Siemens SIMATIC NET S7-300 User Manual

7 Programming FCs (Functions) and FBs for S7 Ethernet CPs
A-209
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
7.4 FCs for Access Coordination with FETCH/WRITE
Overview
The following FCs are available for FETCH/WRITE function to coordinate access:
FC
can be used with:
Meaning
S7 - 300 S7 - 400
AG_LOCK (FC7) x x Locks external data access
with FETCH/WRITE.
AG_UNLOCK (FC8) x x Releases external data
access with FETCH/WRITE.
Caution when Configuring
If you use FCs AG_LOCK and AG_UNLOCK, you must specify the following
information for S7-400 stations in the configuration:
 in HW Config
In the “Addresses” tab, the option “Address setting for LOCK/UNLOCK” must
be selected.
How the Block Works
With these FCs, you can coordinate access to system memory areas so that no
inconsistent data are created and transferred. The control is from the user program
in the S7 CPU that can, if necessary disable an external FETCH/WRITE access
using an AG_LOCK call. After a certain time or after the local write/read access is
completed, an AG_UNLOCK job can be used to enable external access again.
Another advantage is that this access lock only applies to the FETCH/WRITE
connection specified in the call. If more than one FETCH/WRITE connection is
configured, these can, for example, be used for certain specific system areas and
a selective access coordination can be implemented.
The following diagram illustrates the usual chronological sequence of memory
access coordination controlled in the user program with AG_LOCK and
AG_UNLOCK.

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
