Siemens SIMATIC NET S7-300 User Manual

7 Programming FCs (Functions) and FBs for S7 Ethernet CPs
A-231
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
Table 7-9 Condition Codes for FB55 IP_CONFIG, Fortsetzung
DONE MeaningSTATUSERROR
0 1 8B0AH Data error
The content of the subfield is not correct.
01 8B0BH Structure error
A subfield exists twice.
01 8B0CH Data error
The parameter does not contain all the necessary parameters.
01 8B0DH Data error
The CONF_DB does not contain a parameter field for system data.
01 8B0EH Data error / structure error
The CONF_DB type is invalid.
01 8B0FH System error
The CP does not have enough resources to process CONF_DB
completely.
01 8B10
H
Data error
Configuration by the user program is not set.
01 8B11
H
Data error
The specified type of the parameter field is invalid.
01 8B12
H
Data error
Too many connections were specified (either in total or too many for a
specific type; for example, only one E-mail connection is possible).
01 8B13
H
CP-internal error
Further errors detected on the program interfaces within the CPU (SFC errors).
01
8F22H Area length error reading a parameter (e.g. DB too short).
01 8F23H Area length error writing a parameter (e.g. DB too short).
01 8F24H Area error reading a parameter.
01 8F25H Area error writing a parameter.
01 8F28H Alignment error reading a parameter.
01 8F29H Alignment error writing a parameter.
01 8F30H The parameter is in the write-protected first current data block.
01 8F31H The parameter is in the write-protected second current data block.
01 8F32H The parameter contains a DB number that is too high.
01 8F33H DB number error
01 8F3AH The target area was not loaded (DB).
01 8F42H Timeout reading a parameter from the I/O area.
01 8F43H Timeout writing a parameter to the I/O area.
01 8F44H Address of the parameter to be read is disabled in the accessed rack.
01 8F45H Address of the parameter to be written is disabled in the accessed rack.
01 8F7FH Internal error
For example, an illegal ANY reference was detected.
FB55 IP_CONFIG - continued

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
