7 Programming FCs (Functions) and FBs for S7 Ethernet CPs

A-233

S7-CPs for Industrial Ethernet Configuring and Commissioning

Release 01/2007

C79000-G8976-C182-07

Note

For more detailed information on handling the interface DB, refer to the SIMATIC

iMap documentation /19/.

Notice

When you reload user program blocks, data consistency is only guaranteed if the

CPU is first changed to STOP.

How supplied - block library

FB88 and FB90 are supplied with SIMATIC iMap. There are different block types

for S7-300 and S7-400.

After installation, the blocks are available in the PROFINET Library under

“PROFINET_System_Library/CP300 or /CP400”.

Call Interface

Call interface in FBD representation

LADDR DONE

FB88 / FB90

ERROR

STATUS

WORD

BOOL

Call example in STL representation

STL Explanation

Call FB 88 , DB88

LADDR := W#16#0120

DONE := M 99.1

ERROR := M 99.0

STATUS := MW 104

//Block call with instance DB88

Explanation of the Formal Parameters

The following table explains all the formal parameters for FB88 / FB90:

FB88 PN_InOut / FB90 PN_InOut_Fast - continued
