7 Programming FCs (Functions) and FBs for S7 Ethernet CPs
A-241
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
Paramete
r
RemarksPossible
Values
TypeDeclarati
on
DONE OUTPUT BOOL 0: -
1: New data
accepted
This parameter indicates whether or not the
job was completed without errors.
ERROR OUTPUT BOOL 0: -
1: Error
Error code
STATUS OUTPUT WORD - Status code
See Table 7-11 Page A-242
CHECK_
IOCS
OUTPUT BOOL 0: All IOCS set to
GOOD
1: At least one
IOCS set to BAD
Auxiliary bit that indicates whether or not it is
necessary to evaluate the IOCS status area
IOCS OUTPUT ANY (as
VARTYP
E only
BYTE is
permitted
)
The address of
the data area
points to one of
the alternatives:
 Memory bit
area
 Data block
area
Length:
For the maximum
value, refer to the
device-specific
Part B of this
manual in the
“Performance
Data” chapter.
This may differ for
controller or
device mode.
A status bit is transferred per byte of user
data.
The length information depends on the
length in the LEN parameter (one bit per
byte)
= (Length LEN + 7/ 8)
Controller mode:
Address gaps are also transferred according
to the SEND parameter.
Address gaps are transferred with the status
GOOD.
Device mode:
Address gaps are not transferred.
The block begins the transfer of the status
for address 0.
Notes:
 The minimum length of the ANY pointer
is (length LEN + 7/ 8)
Note
Remember that all output parameters may only be evaluated when the block
signals either DONE = 1 or ERROR = 1.
Notice
You must assume that the returned IOCS status does not arrive time-synchronized
with the data (SEND parameter) but delayed by one user program cycle. This
means: User data and IOCS are not consistent.
FC11 PNIO_SEND - continued

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
