Siemens SIMATIC NET S7-300 User Manual

7 Programming FCs (Functions) and FBs for S7 Ethernet CPs
A-259
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
Note
For entries with the coding 8Fxx
H
note the information under STATUS in the
Reference Manual “STEP 7 - System and Standard Functions for S7-300 and
S7-400”. The chapter describing error evaluation with the RET_VAL output
parameter contains detailed information.
Table 7-14 Condition Codes PNIO_ALARM
DONE
NEW ERROR STATUS Meaning
0
0
0 8180H Data transfer active
1
1
0 0000H Alarm data successfully transferred and alarm acknowledged
1
0
0 0000H No alarm data exist
0
0
1 8183H  No PNIO controller configuration,
 wrong CPLADDR
or
 CP in STOP mode
0
0
1 8184H System error or illegal parameter type
0
0
1 8185H Destination buffer (TINFO or AINFO) is too short
0
0
1 8F22H Area length error reading a parameter (e.g. DB too short)
0
0
1 8F23H Area length error writing a parameter (e.g. DB too short)
0
0
1 8F24H Area error reading a parameter
0
0
1 8F25H Area error writing a parameter
0
0
1 8F28H Alignment error reading a parameter
0
0
1 8F29H Alignment error writing a parameter
0
0
1 8F30H Parameter is in the write-protected first active data block
0
0
1 8F31H Parameter is in the write-protected second active data block
0
0
1 8F32H Parameter contains a DB number that is too high
0
0
1 8F3AH Destination area not loaded (DB)
0
0
1 8F42H Timeout reading a parameter from the I/O area
0
0
1 8F43H Timeout writing a parameter to the I/O area
0
0
1 8F44H Address of the parameter to be read is disabled in the
accessed rack
0
0
1 8F45H Address of the parameter to be written is disabled in the
accessed rack
0
0
1 8F7FH Internal error, e.g. illegal ANY reference.
0
0
1 8090H Module with this address does not exist
0
0
1 80A0H Negative acknowledgment reading from the module
0
0
1 80A1H Negative acknowledgment writing to the module
