1 Communication via Ethernet CPs in S7 Stations
A-29
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
Configuring S7 Connections
Create S7 connections to use S7 communication for data exchange between two
SIMATIC S7 stations.
For more detailed information, refer to the STEP 7 Description /6/.
Notice
S7 connections via routers are supported only within a STEP 7 project but not
between partners in different STEP 7 projects of a multiproject!
Interface in the User Program of the S7 Station
You use SFBs (for S7-400) and FBs (for S7-300) in the user program.
Block Type Client Server Described in
SFB / FB12 BSEND x - STEP 7
D t ti /8/
SFB / FB13 BRCV x
Documentation /8/
SFB / FB15 PUT x -
1)
SFB / FB14 GET x -
1)
SFB / FB8 USEND x -
SFB / FB9 URCV - x
SFC / FC62 CONTROL (S7-400) /
C_CNTRL (S7-300)
x x
2)
1)
you do not need to configure a connection on the server
2)
for S7-300
Notice
Please remember the following points regarding data consistency in your user
program:
In the CPU of the S7 station, the read or written information is taken from the S7
user program into the operating system or copied from the operating system to the
S7 user program in blocks of 8 or 32 bytes (depending on the firmware version).
If information in the word or double-word format is located across such
boundaries, data inconsistency may arise during transmission using S7
communication!
For more detailed information, refer to the STEP 7 documentation /8/.

Siemens SIMATIC NET S7-300 Specifications

General

Product Type Designation	SIMATIC NET S7-300
Mounting	DIN rail mounting
Protection Class	IP20
CPU Models	Various models available (e.g., CPU 312, CPU 314)
Communication Interfaces	MPI, PROFIBUS DP
Power Supply	24 V DC power supply required. Different power supply modules available.
I/O Modules	Digital input modules, digital output modules, analog input modules, analog output modules
Programming	STEP 7 software
Supply Voltage	24V DC or 120/230V AC (depending on model)
Digital Inputs	Available via digital input modules
Digital Outputs	Available via digital output modules
Analog Inputs	Available via analog input modules
Analog Outputs	Available via analog output modules
Communication Functions	MPI, PROFIBUS DP, Ethernet (depending on model)
Protocols	MPI, PROFIBUS DP, TCP/IP (depending on model)
Operating Temperature	0°C to 60°C
Storage Temperature	70 °C
Memory	Depends on CPU model (e.g., 32 KB to 1.5 MB)
