B Standards and Approvals for SIMATIC NET S7-CPs
A-290
S7-CPs for Industrial Ethernet Configuring and Commissioning
Release 01/2007
C79000-G8976-C182-07
UL Approval
UL Recognition Mark Underwriters Laboratories (UL) according to standard UL
508:
Report E 85972
CSA Approval
CSA Certification Mark Canadian Standard Association (CSA) according to
standard C 22.2 No. 142:
Certification Record 063533–C-000
cULus Approval, Hazardous Location
CULUS Listed 7RA9 IND. CONT. EQ. FOR HAZ. LOC.
Underwriters Laboratories Inc. according to
UL 508 (Industrial Control Equipment)
CSA C22.2 No. 142 (Process Control Equipment)
UL 1604 (Hazardous Location)
CSA–213 (Hazardous Location)
APPROVED for Use in
Cl. 1, Div. 2, GP. A, B, C, D T4A
Cl. 1, Zone 2, GP. IIC T4
Cl. 1, Zone 2, AEx nC IIC T4
!
Warning
Explosion Hazard -
Do not disconnect while circuit is live unless area is known to be non hazardous.
!
Warning
Explosion Hazard -
Substitution of components may impair suitability for Class I, Division 2.
